High-Performance Algorithms for Automated Saw Machining

Mai 9, 2019

ModuleWorks has developed new toolpath algorithms that boost the efficiency and quality of saw machining. ModuleWorks will showcase the new technology at LIGNA 2019 (Hall 015, Stand D29, 27 – 31 May 2019, Hannover, Germany).


The new algorithms bring greater automation to the saw milling process. This increases productivity as well as the quality of the machined product. The intelligent algorithms automatically determine the required infeed for trimming and provide fully-automatic control of the tool-axis along the toolpath, including the inner corners. To prevent breakouts on the top layer, the algorithm offers a pre-scoring functionality.

After sawing, the new corner clearing cycle accelerates the finishing process by making it easier to remove inclined-plane intersections from the inner corners. The system automatically adjusts the tool axis to fit a suitable taper or chamfer mill into the corner. The direction and length of the cut is determined automatically.

In addition to the new saw machining algorithms, visitors to the ModuleWorks booth at LIGNA 2019 will also see realistic wood cutting simulation with support for virtually any router configuration including replaceable heads, drill blocks and vacuum heads. The simulation shows all toolpaths including drill blocks, 4-way aggregates and saw cutting.

For multi-axis machining, the latest ModuleWorks toolpath generation components deliver state-of-the-art and innovative machining toolpaths for generic and specialized woodworking applications:

5-axis routers

For 5-axis routers, ModuleWorks offers the full range of performance-optimizing toolpath cycles, from simple 2D pocketing and 3D parts to sophisticated 5-axis operations with complex part geometries.

Beams

A wide range of ModuleWorks toolpaths have been fine-tuned for specialized beam machining, including carpentry joining, contract joining and frame construction.

Cabinets, doors and windows

For large parts such as cabinets, doors and windows, ModuleWorks offers dedicated prismatic roughing, finishing and drilling cycles.

Sculptured surfaces, sign making and reliefs

ModuleWorks software components bring all the advantages of high-end CAM technology to artistic applications such as sculptured surfaces and sign making. The versatile components can be used to produce any shape in any material.
